MAXI TAIL WHEEL WILL NOT WORK WITH THIS KIT
Type 1/3 scale 2-place Military / Civil Biplane
Wing Span 116 inches top, 111 inches bottom
Wing Cord 18 inches both wings
Wing Area 3617 Sq. inches
Tail Span 46 inches
Airfoil Semi-Symmetrical
Wing Loading 25-1/2 ~ 32 Oz / Sq. Foot.
Flying Weight 40 ~ 50 Lbs
Fuselage length 92 inches
Height 36 inches (flight ready)
Height of Rudder 24 inches (tail wheel to tip)
Engine Size 4.3 to 15.2 Cubic inch (70 to 250cc Moky Radial
Radio Gear 4-Channel W/5 Servos min. 150 Oz Torque min.
Cowl Diameter 13-1/2”
Model Features
Precision Giant Scale landing gear “fully assembled”
Balsa, Bass, Plywood, and Aluminum Construction.
Separate “plug in” wing panels (both Top and Bottom).
Kit includes
Rolled Full Size Plans & Photo Instructions.
Complete Hardware package (including all push rods and cables).
Complete interior kit (includes seats and instrument panel)
Scale aluminum landing gear W/ functional coil spring suspension and wheels.
Scale leaf spring tail wheel assembly W/wheel
Scale “pull, pull” rudder control system W/ bell crank and cables
Spun Aluminum Cowl
Aluminum and ABS plastic fairings, covers and “boot” cowl
Fully functional flying and landing wires W/ all fittings.
Scale 3-View Drawings.
Items Needed to Complete
Covering material (5, 5-meter rolls Oratex recommended)
Paint, Engine, and Radio,
Notes
Center of Gravity 8-3/4 inch back from leading edge of top wing
Control Throws: Incidence
Elevator ……..... 2-1/4” Up & Down Top Wing ………… +1/2~1 Degrees
Rudder ……..… 4” Left & Right Bottom Wing …….. -1/2~0.0 Degrees
Ailerons ..…….. 2” Up & Down Tail ……………….. 0.0 Degrees
Aileron Differential ………... 2” Up & 1-1/2” Down (differential recommended)
Engine Thrust Line …….…... 2 Degrees DOWN, 1~2 Degrees RIGHT
