Type ¼ Scale German WW-I Late War Fighter
Wing Span 88-1/2 Inches (17-1/2” cord)
Wing Area 1507 Square Inches total.
Airfoil Flat Bottom
Wing Loading 35 ~ 42 Oz. / Sq. Foot
Fuselage Length 63-3/4 Inches.
Flying Weight 23 to 28 Pounds
Engine Size Gasoline 35 ~ 62cc
Prop Size Depends on engine being used
Fuel Tank 16~24 Oz. (compatible with fuel requirements of engine)
Radio Equipment 4-Channel W/ 5 servos min.
Servo Requirements High torque 70 ~ 100 In. / Oz. std. Size High Torque Servos
Wheel Size 6-5/8 vintage (Not included in kit)
Engine Compartment 5.8 X 11-1/2"
Scale prop 27”
Model Features
Balsa, Bass, and Ply construction
Removable “3-piece” bolt on wing
Full Flying Rudder
Kit Includes
Full-Size plans W/ photo instruction book.
Jig & die cut parts
Pre-bent wire landing gear W/Fairings
Basic hardware package
Pull-Pull Rudder cables
Built up wooden cowl.
Items Needed to Complete
Control system (push rod type or pull / pull cable system suitable for a model of this size)
Fuel System (fuel tank & fuel lines) compatible with the fuel requirements of engine used.
6 yards, 1/2 ounce fiberglass cloth and finishing resin
1-pair 6-5/8 Vintage wheels
Notes
Center of Gravity 5 Inches back from leading edge of Wing.
Control Throws:
Elevator ………………….. 3/4~1” Up and Down
Rudder …………………… 1~1-1/2” Left and Right
Ailerons ………………….. 3/4 ~ 1” Up and Down
(Aileron differential recommended 1" Up 3/4” Down)
Thrust Line Offset
1 Degrees DOWN, 1Degree RIGHT
1/4 Scale Junkers D-1 Decals “German, Late War, Lateen (straight) Crosses”
(4) Large 16 Inch Crosses with White Outlines ….................... Top & Bottom Wing
(2) Smaller 8 Inch Crosses with white outlines ………………. Fuselage Sides
(2) Smaller 8 inch Crosses NO White Outline ……………….. Rudder
|
